Product Summary
| Standard Package | 250 |
|---|---|
| Category | Capacitors |
| Family | Ceramic Capacitors |
| Series | KX |
| Capacitance | 2200pF |
| Voltage - Rated | 250VAC |
| Tolerance | ±20% |
| Temperature Coefficient | E |
| Mounting Type | Through Hole |
| Operating Temperature | -25°C ~ 85°C |
| Applications | Safety |
| Ratings | X1Y1 |
| Package / Case | Radial, Disc |
| Size / Dimension | 0.354" Dia (9.00mm) |
| Height - Seated (Max) | 0.472" (12.00mm) |
| Thickness (Max) | - |
| Lead Spacing | 0.394" (10.00mm) |
| Features | High Voltage |
| Packaging | Bulk |
| Lead Style | Straight |
Parametrics
Capacitance: 2200 pF
Tolerance: 20 %
Voltage Rating: 250 V
Operating Temperature Range: - 25 C to + 125 C
Termination Style: Radial
Product: High Voltage Ceramic Disc Capacitors
Capacitance - nF: 2.2 nF
Capacitance - uF: 0.0022 uF
Case Diameter: 9 mm
Dimensions: 9 mm Dia.
Lead Spacing: 10 mm
Features
1. We design capacitors in much more compact size than
current Type KX, having reduced the diameter
by 20% max.
2. Operating temperature range guaranteed up to 125
degrees (UL: 85 deg.).
3. Dielectric strength: AC4000V
4. Class X1/Y1 capacitors which are recognized by
UL/CSA/BSI/SEMKO/SEV/VDE/FIMKO/NEMKO/DEMKO/
IMQ.
5. Possible to use with a component in appliance
requiring reinforced insulation and double
insulation based on UL1492, IEC60065 and IEC60950.
6. Coated with flame-retardant epoxy resin (conforming
to UL94V-0 standard).
7. Cost-saving automatic insertion available.
8. Available product for RoHS Restriction
(EU Directive 2002/95/EC).
Diagrams
