Product Summary
The ZY1120G-T3 is an intelligent, fully programmable step-down point-of-load DC-DC module integrating digital power conversion and intelligent power management. The ZY1120G-T3 completely eliminates the need for external components for sequencing, tracking, protection, monitoring, and reporting. Performance parameters of the ZY1120G-T3 are programmable by pin strapping and external resistor and capacitor and can be changed by a user at any time during product development and service without a need for a communication bus. Power One point-of-load converters are recommended for use with regulated bus converters in an Intermediate Bus Architecture (IBA).
Parametrics
ZY1120G-T3 absolute maximum ratings: (1)Operating Temperature Controller Case Temperature: -40 to 105 ℃; (2)Input Voltage 250ms Transient: 15 VDC; (3)Output Current (See Output Current Derating Curves): -20 to 20 ADC.
Features
ZY1120G-T3 features: (1)RoHS lead free and lead-solder-exempt products are available; (2)Wide input voltage range: 3V4V; (3)High continuous output current: 20A; (4)Wide programmable output voltage range: 0.5V.5V; (5)Active digital current share; (6)Output voltage margining; (7)Overcurrent and overtemperature protections; (8)Programmable power-up delay; (9)Sequenced and cascaded modes of operation; (10)Programmable interleave; (11)Programmable feedback loop compensation; (12)Enable control with programmable polarity; (13)Flexible fault management and propagation; (14)Start-up into the load pre-biased up to 100%; (15)Full rated current sink; (16)Small footprint vertical SMT package: 8x32mm; (17)Low profile of 14mm; (18)Wide operating temperature range.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ZY1120G-T3 |
Power-One |
DC/DC Converters 50 pcs |
Data Sheet |
|
|
|||||||||||||
