AM29LV128ML

128 Megabit, MirrorBit, 3.0 Volt-only, Uniform Sector, Flash Memory, TSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $7.10~7.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $7.10~7.10

PartNumber:: AM29LV128ML

Brand:: Advanced Micro Devices - AMD | Pack: TSOP | D/C: 11+

Availability:: Supply Ability: 3/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. helen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-20

From Other Seller

Part Number:AM29LV128ML
US $7.10 - 7.10
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
AT45DB161B-TU

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AM29LV128ML is a 128 Mbit, 3.0 volt single power supply flash memory devices organized as 8,388,608 words or 16,777,216 bytes. The AM29LV128ML has a 16-bit wide data bus that can also function as an 8-bit wide data bus by using the BYTE# input. The AM29LV128ML can be programmed either in the host system or in standard EPROM programmers. The AM29LV128ML requires only a single 3.0 volt power supply for both read and write functions. In addition to a VCC input, a high-voltage accelerated program (WP#/ACC) input provides shorter programming times through increased current. This feature is intended to facilitate factory throughput during system production, but may also be used in the field if desired.

Parametrics

AM29LV128ML absolute maximum ratings: (1)Plastic Packages: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –65℃ to +125℃; (3)Voltage with Respect to Ground; (4)VCC: –0.5 V to +4.0 V; (5)VIO: –0.5 V to +4.0 V; (6)All other pins: –0.5 V to VCC +0.5 V; (7)Output Short Circuit Current : 200 mA.

Features

AM29LV128ML features: (1)Single power supply operation; (2)VersatileI/O control; (3)Manufactured on 0.23 μm MirrorBit process technology; (4)Secured Silicon Sector region; (5)Flexible sector architecture; (6)Compatibility with JEDEC standards; (7)Minimum 100,000 erase cycle guarantee per sector; (8)20-year data retention at 125℃; (9)High performance.
