Product Summary

The AT24C02BN-SH-T is a two-wire automotive temperature serial EEPROM. It provides 2048 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 256 words of 8 bits each. The AT24C02BN-SH-T is optimized for use in many automotive applications where low-power and low-voltage operation are essential. It is available in space-saving 8-lead JEDEC SOIC and 8-lead TSSOP packages and is accessed via a two-wire serial interface.

Parametrics

AT24C02BN-SH-T absolute maximum ratings: (1)Operating Temperature: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: -1.0V to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0mA.

Features

AT24C02BN-SH-T features: (1)Automotive Temperature Range -40℃ to 125℃; (2)Internally Organized 128 × 8 (1K), 256 × 8 (2K), 512 × 8 (4K) or 1024 × 8 (8K); (3)Two-wire Serial Interface; (4)Schmitt Trigger, Filtered Inputs for Noise Suppression; (5)Bidirectional Data Transfer Protocol; (6)400 kHz (2.5V) Compatibility; (7)Write Protect Pin for Hardware Data Protection; (8)8-byte Page (1K, 2K) or 16-byte Page (4K, 8K) Write Modes; (9)Partial Page Writes are Allowed; (10)Self-timed Write Cycle (5 ms max).
