Product Summary

The BAS16HT1G is a Switching Diode.

Parametrics

BAS16HT1G absolute maximum ratings: (1)Continuous Reverse Voltage, VR: 75 Vdc; (2)Peak Forward Current, IF: 200 mAdc; (3)Peak Forward Surge Current, IFM(surge): 500 mAdc.

Features

BAS16HT1G features: (1)Reverse Voltage Leakage Current (VR = 75 Vdc), IR: 1.0μAdc; (2)Reverse Breakdown Voltage (IBR = 100 mAdc), V(BR): 75Vdc; (3)Forward Voltage, VF: 715mV; (4)Diode Capacitance (VR = 0, f = 1.0 MHz), CD: 2.0 pF; (5)Forward Recovery Voltage (IF = 10 mAdc, tr = 20 ns), VFR: 1.75Vdc; (6)Reverse Recovery Time (IF = IR = 10 mAdc, RL = 50 W), trr: 6.0ns; (7)Stored Charge (IF = 10 mAdc to VR = 5.0 Vdc, RL = 500 W), QS: 45pC.

Diagrams

BAS16HT1G circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BAS16HT1G
BAS16HT1G
ON Semiconductor
Diodes (General Purpose, Power, Switching) 75V 200mA
Data Sheet
0-1: $0.12
1-25: $0.09
25-100: $0.04
100-500: $0.03
