Product Summary

The BC847B is an NPN general purpose transistor. It is in a SOT23 plastic package. The device is designed for general purpose switching and amplification.

Parametrics

BC847B absolute maximum ratings: (1)VCBO collector-base voltage: 50 V; (2)VCEO collector-emitter voltage: 45 V; (3)VEBO emitter-base voltage: 6 V; (4)IC collector current (DC): 100 mA; (5)ICM peak collector current: 200 mA; (6)IBM peak base current: 200 mA; (7)Ptot total power dissipation: 250 mW; (8)Tstg storage temperature: -65 to +150 ℃; (9)Tj junction temperature: 150 ℃; (10)Tamb operating ambient temperature: -65 to +150 ℃.

Features

BC847B features: (1)Low current (max. 100 mA); (2)Low voltage (max. 65 V).

Diagrams

BC847B circuit diagram
