Product Summary
The LMV932MAX is low voltage, low power operational amplifiers.LMV932MAX is guaranteed to operate from +1.8V to +5.0V supply voltages and have rail-to-rail input and output. LMV932MAX input common mode voltage extends 200mV beyond the supplies which enables user enhanced functionality beyond the supply voltage range. The output can swing rail-to-rail unloaded and within 105mV from the rail with 600Ω load at 1.8V supply. The LMV932MAX is optimized to work at 1.8V which make them ideal for portable two-cell battery powered systems and single cell Li-Ion systems. LMV932MAX exhibit excellent speed-power ratio, achieving 1.4MHz gain bandwidth product at 1.8V supply voltage with very low supply current. The LMV932MAX is capable of driving a 600Ω load and up to 1000pF capacitive load with minimal ringing. LMV932MAX has a high DC gain of 101dB, making them suitable for low frequency applications. The dual LMV932MAX are in MSOP-8 and SOIC-8 packages and the quad LMV934 are in TSSOP-14 and SOIC-14 packages. These small packages are ideal solutions for area constrained PC boards and portable electronics such as cellular phones and PDAs.
Parametrics
Absolute maximum ratings:(1)ESD Tolerance, Machine Model: 200V; (2)Human Body Model: 2000V; (3)Differential Input Voltage: ±Supply Voltage; (4)Supply Voltage (V+–V-): 5.5V; (5)Storage Temperature Range: -65℃ to 150℃; (6)Junction Temperature: 150℃; (7)Mounting Temp Infrared or Convection (20 sec): 235℃.
Features
Features:(1)Guaranteed 1.8V, 2.7V and 5V specifications; (2)Output swing; (3)w/600Ω load 80mV from rail; (4)w/2kΩ load 30mV from rail; (5)VCM 200mV beyond rails; (6)Supply current (per channel) 100μA; (7)Gain bandwidth product 1.4MHz; (8)Maximum VOS 4.0mV; (9)Ultra tiny packages; (10)Temperature range.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LMV932MAX |
National Semiconductor (TI) |
Operational Amplifiers - Op Amps |
Data Sheet |
|
|
|||||||||||||
LMV932MAX/NOPB |
National Semiconductor (TI) |
Operational Amplifiers - Op Amps |
Data Sheet |
|
|
