Product Summary

The BP4U+ is a Power Splitter/Combiner. The applications of the BP4U+ include PCS/DCS, GSM, WCDMA.

Parametrics

BP4U+ absolute maximum ratings: (1)Operating Temperature: -40℃ to 85℃; (2)Storage Temperature: -65℃ to 150℃; (3)Power Input (as a splitter): 1.5W max; (4)Internal Dissipation: 0.375W max.

Features

BP4U+ features: (1)low insertion loss, 0.8 dB typ; (2)excellent output VSWR, 1.25:1 typ; (3)aqueous washable; (4)excellent power handling, 1.5W.

Diagrams
