Product Summary
The MSP430F168IPMR is a microcontroller configuration with two built-in 16-bit timers, a fast 12-bit A/D converter, dual 12-bit D/A converter, one or two universal serial synchronous/asynchronous communication interfaces (USART), I2C, DMA, and 48 I/O pins. Its typical applications include sensor systems, industrial control applications, hand-held meters, etc.
Parametrics
Absolute maximum ratings over operating free-air temperature: (1)Voltage applied at VCC to VSS: 0.3 V to 4.1 V; (2)Voltage applied to any pin (see Note): 0.3 V to VCC + 0.3 V; (3)Diode current at any device terminal: ±2 mA; (4)Storage temperature, Tstg: Unprogrammed device: 55℃ to 150℃; (5)Programmed device: 55℃ to 85℃.
Features
Features: (1)Five Power-Saving Modes; (2)Wake-Up From Standby Mode in Less Than 6 μs; (3)16-Bit RISC Architecture, 125-ns Instruction Cycle Time; (4)Three-Channel Internal DMA; (5)12-Bit Analog-to-Digital (A/D) Converter With Internal Reference, Sample-and-Hold, and Autoscan Feature; (6)Dual 12-Bit Digital-to-Analog (D/A) Converters With Synchronization; (7)16-Bit Timer_A With Three Capture/Compare Registers; (8)16-Bit Timer_B With Three or Seven Capture/Compare-With-Shadow Registers; (9)On-Chip Comparator; (10)Serial Communication Interface (USART0), Functions as Asynchronous UART or Synchronous SPI or I2CTM Interface.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MSP430F168IPMR |
Texas Instruments |
16-bit Microcontrollers (MCU) 48kB Flash 2MB RAM 12-Bit ADC/Dual DAC |
Data Sheet |
|
|
|||||||||
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||
MSP4120 |
Other |
Data Sheet |
Negotiable |
|
||||||||||
MSP4200 |
Other |
Data Sheet |
Negotiable |
|
||||||||||
MSP430×11× |
Other |
Data Sheet |
Negotiable |
|
||||||||||
MSP430×11×2 |
Other |
Data Sheet |
Negotiable |
|
||||||||||
MSP430×12×2 |
Other |
Data Sheet |
Negotiable |
|
||||||||||
MSP430×21×1 |
Other |
Data Sheet |
Negotiable |
|
