Product Summary

The LFCN-3800+ is a Low Pass Filter. The applications of LFCN-3800+ are: harmonic rejection, VHF/UHF transmitters/receivers, lab use.

Parametrics

LFCN-3800+ absolute maximum ratings: (1)Operating Temperature: -55℃ to 100℃; (2)Storage Temperature: -55℃ to 100℃; (3)RF Power Input: 8W max. at 25℃; (4)DC Current Input to Output: 0.5A max. at 25℃.

Features

LFCN-3800+ features: (1)excellent power handling, 8W; (2)small size; (3)7 sections; (4)temperature stable; (5)hermetically sealed; (6)LTCC construction; (7)protected by U.S. Patent 6,943,646.

Diagrams

LFCN-3800+ outline drawing
