Product Summary
The SN74HC08PWR is a quadruple 2-input positive-and gate. The SN74HC08PWR contains four independent 2-input AND gates. It performs the Boolean function Y = A · B or Y = A + B in positive logic.
Parametrics
SN74HC08PWR absolute maximum ratings: (1)Supply voltage range, VCC: -0.5 V to 7 V; (2)Input clamp current, IIK (VI < 0 or VI > VCC): ±20 mA; (3)Output clamp current, IOK (VO < 0 or VO > VCC): ±20 mA; (4)Continuous output current, IO (VO = 0 to VCC): ±25 mA; (5)Continuous current through VCC or GND: ±50 mA; (6)Storage temperature range, Tstg: -65℃ to 150℃.
Features
SN74HC08PWR features: (1)Wide Operating Voltage Range of 2 V to 6 V; (2)Outputs Can Drive Up To 10 LSTTL Loads; (3)Low Power Consumption, 20-μA Max ICC; (4)Typical tpd = 8 ns; (5)±4-mA Output Drive at 5 V; (6)Low Input Current of 1 μA Max.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SN74HC08PWR |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quad 2-Input. |
Data Sheet |
|
|
|||||||||||||
SN74HC08PWRE4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Positive-AND Gates |
Data Sheet |
|
|
|||||||||||||
SN74HC08PWRG4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Positive-AND Gates |
Data Sheet |
|
|
