Product Summary
The SN74HCT14N is a HEX schmitt-trigger inverter. The SN74HCT14N contains six independent inverters. The device performs the Boolean function Y = A in positive logic. The SN74HCT14N is characterized for operation from -40℃ to 85℃.
Parametrics
SN74HCT14N absolute maximum ratings: (1)Supply voltage range, VCC: -0.5 V to 7 V; (2)Input voltage range, VI: -0.5 V to VCC +0.5 V; (3)Output voltage range, VO: -0.5 V to VCC +0.5 V; (4)Input clamp current, IIK (VI < 0 or VI > VCC): ±20 mA; (5)Output clamp current, IOK (VO < 0 or VO > VCC): ±20 mA; (6)Continuous output current, IO (VO = 0 to VCC): ±25 mA; (7)Continuous current through VCC or GND: ±50 mA; (8)Storage temperature range, Tstg: -65℃ to 150℃.
Features
SN74HCT14N features: (1)Inputs Are TTL-Voltage Compatible; (2)Package Options Include Plastic Small-Outline (D), Shrink Small-Outline (DB), Thin Very Small-Outline (DGV), Thin Shrink Small-Outline (PW), and Ceramic Flat (W) Packages, Ceramic Chip Carriers (FK), and Standard Plastic (N) and Ceramic (J) DIPs.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74HCT14N |
Texas Instruments |
Inverters Hex Schmitt-Trigger |
Data Sheet |
|
|
||||||||||||
|
SN74HCT14NE4 |
Texas Instruments |
Inverters Hex Schmitt-Trigger Inverters |
Data Sheet |
|
|
||||||||||||
