IRFPS37N50APBF

SMPS MOSFET, SMD, 36A, Low Gate Charge Qg results, Effective Coss Specified, ± 30V, 446W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.64~2.87 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.64~2.87

PartNumber:: IRFPS37N50APBF

Brand:: Vishay Siliconix - vishay | Pack: SMD | D/C: 11+

Availability:: Supply Ability: 0/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. helen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-12

From Other Seller

Part Number:IRFPS37N50APBF
US $2.64 - 2.87
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRFPS37N50APBF is a SMPS MOSFET. The device is suitable for Switch Mode Power Supply (SMPS), Uninterruptable Power Supply, High Speed Power Switching and Lead-Free.

Parametrics

IRFPS37N50APBF absolute maximum ratings: (1)ID @ TC = 25℃, Continuous Drain Current, VGS @ 10V: 36A; (2)ID @ TC = 100℃, Continuous Drain Current, VGS @ 10V: 23 A; (3)IDM, Pulsed Drain Current: 144A; (4)PD @TC = 25℃, Power Dissipation: 446 W; (5)Linear Derating Factor: 3.6 W/℃; (6)VGS, Gate-to-Source Voltage: ± 30 V; (7)dv/dt, Peak Diode Recovery dv/dt: 3.5 V/ns; (8)TJ, TSTG, Operating Junction and Storage Temperature Range: -55 to + 150℃; (9)Soldering Temperature, for 10 seconds: 300℃ (1.6mm from case ).

Features

IRFPS37N50APBF features: (1)Low Gate Charge Qg results in Simple Drive Requirement; (2)Improved Gate, Avalanche and Dynamic dv/dt Ruggedness; (3)Fully Characterized Capacitance and Avalanche Voltage and Current; (4)Effective Coss Specified.
