MCP602T-ISN

operational amplifier, TSSOP-8, 7.0V, ±2 mA, MCP602T-ISN, Microchip

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.14~0.15 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.14~0.15

PartNumber:: MCP602T-ISN

Brand:: Microchip Technology - Microchip | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 0/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. helen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-22

From Other Seller

Part Number:MCP602T-ISN
US $0.14 - 0.15
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MCP602T-ISN is a low-power operational amplifier (op amp). It is offered in dual configurations. The MCP602T-ISN utilizes an advanced CMOS technology that provides low bias current, highspeed operation, high open-loop gain, and rail-to-rail output swing. This product offering operates with a single supply voltage that can be as low as 2.7V, while drawing 230 μA (typical) of quiescent current per amplifier. The MCP602T-ISN is appropriate for low power, battery operated circuits due to the low quiescent current, for A/D convert driver amplifiers because of their wide bandwidth or for anti-aliasing filters by virtue of their low input bias current. The MCP602T-ISN is used in Portable Equipment, A/D Converter Driver, Photo Diode Pre-amp, Analog Filters, Data Acquisition, Notebooks and PDAs, Sensor Interface.

Parametrics

MCP602T-ISN absolute maximum ratings: (1)VDD – VSS: 7.0V; (2)Current at Input Pins: ±2 mA; (3)Analog Inputs (VIN+, VIN–): VSS – 1.0V to VDD + 1.0V; (4)All Other Inputs and Outputs: VSS – 0.3V to VDD + 0.3V; (5)Difference Input Voltage: |VDD – VSS|; (6)Output Short Circuit Current: Continuous; (7)Current at Output and Supply Pins: ±30 mA; (8)Storage Temperature: –65℃ to +150℃; (9)Maximum Junction Temperature (TJ): +150℃; (10)ESD Protection On All Pins (HBM; MM): ≥ 3 kV; 200V.

Features

MCP602T-ISN features: (1)Single-Supply: 2.7V to 6.0V; (2)Rail-to-Rail Output; (3)Input Range Includes Ground; (4)Gain Bandwidth Product: 2.8 MHz (typical); (5)Unity-Gain Stable; (6)Low Quiescent Current: 230 μA/amplifier (typical); (7)Chip Select (CS): MCP603 only; (8)Temperature Ranges: Industrial: -40℃ to +85℃; Extended: -40℃ to +125℃; (9)Available in Single, Dual, and Quad.
