Product Summary
The MAX912/MAX913 can be powered from a single
+5V supply or a ±5V split supply. The MAX913 is an
improved plug-in replacement for the LT1016. It pro-
vides significantly wider input voltage range and equiv-
alent speed at a fraction of the power. The MAX912
dual comparator has equal performance to the MAX913
and includes independent latch controls.
Parametrics
Input Voltage Range VCM Single +5V C, E temperature ranges -0.2 +3.5V
Positive supply; 4.5V ≤ V+ ≤ 5.5V 60 85
Power-Supply Rejection Ratio PSRR
Negative supply; -2V ≥ V- ≥ -7V 80 100dB
Output Voltage
TA = +25°C, ISINK = 10mA 0.4V
Features
Ultra Fast (10ns)
Single +5V or Dual ±5V Supply Operation
Input Range Extends Below Negative Supply
Low Power: 6mA (+5V) Per Comparator
No Minimum Input Signal Slew-Rate Requirement
No Power-Supply Current Spiking
Stable in the Linear Region
Inputs Can Exceed Either Supply
Low Offset Voltage: 0.8mV
Now Available in a Small μMAX Package
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX913ESA |
Maxim Integrated Products |
Comparator ICs Single Precision TTL Comparator |
Data Sheet |
|
|
||||||||||||
 |
MAX913ESA+ |
Maxim Integrated Products |
Comparator ICs Single Precision TTL Comparator |
Data Sheet |
|
|
||||||||||||
|
MAX913ESA+T |
Maxim Integrated Products |
Comparator ICs Single Precision TTL Comparator |
Data Sheet |
|
|
||||||||||||
|
MAX913ESA-T |
Maxim Integrated Products |
Comparator ICs Single Precision TTL Comparator |
Data Sheet |
|
|
||||||||||||
